Zigzag. The Geometric Three Bedroom Modern Home
Includes PDF, CAD & Sketchup digital plan files. Read about ‘What’s In A House Plan’.

$2,267

SKU: THP270 Category: Tags: , Brand:

Zigzag House Plan’s design is centered around two opposing and alternating structures which are oriented along the lines of two equilateral triangles. The lower level holds the garage and two bedrooms. The upper level is the master suite, living spaces and large entertaining kitchen.

Features of the Zigzag House Plan include:

  • Three Bedrooms
  • Three Baths
  • Downstairs Laundry
  • Central Reception Room
  • Large Entertaining Kitchen with Island
  • Outdoor Kitchen with Vented Grill
  • Three Rooftop Decks
  • Three Covered Ground Level Patios
File Formats

PDF, DWG (Cad File), LAYOUT (Sketchup Pro Layout File), SKP (Sketchup 3D Model)

Beds

Baths

Stories / Levels

Parking

1 Parking Space

Living Area (sq. ft.)

Parking Area (sq. ft.)

311

Under Roof Area (sq. ft.)

3216

Width (feet)

Depth (feet)

70

Height (feet)

Ceilings

10 foot ceilings throughout

Construction

The roof is a TPO / Membrane system., The foundation is a concrete stem wall, The floor is a concrete slab., The exterior walls are 2×6 wood framing., The upper floor is pre-engineered wood trusses., The roof is pre-engineered wood trusses.

Doors & Windows

Modern doors and windows

Features

Exterior Finishes

Concrete or Wood Lap Siding, Glass Railing, Membrane Roofing System, Stacked Stone

Mechanical

Ductless air-conditioning system

Styles

, ,

Collections

,

Brand

Tyree House Plans

Add Readable Reverse (Flip Plan)

Reverse this house plan by flipping the plan left-to-right. All text will remain readable on the reversed plans.

$300

Need Changes Made To This Plan?

We look forward to giving your project the attention and time that it deserves, and perfecting your dream house plans. Learn about the process for changing a plan.
