1581 Square Feet
First Floor 1185 s.f.
Second Floor 396 s.f.
Porches 392 s.f.
Under Roof 1973 s.f.
below the house structure, between the pilings.
10 Foot Ceilings
and 9 foot ceilings upstairs
62′ deep (without stairs)
Doors & Windows
We specify double hung windows throughout most of the home to preserve the historic look. These are available in durable materials.
Use code THANKSGIVING for 15% off at checkout.
What's In This Plan
Floor plans are views of each floor, looking down from above. The plans show window and door locations, room sizes, cabinets and fixtures.
Exterior elevations are flat views of the outside of the house, looking at the front, left, rear and right.
Building sections show cutaway views of the home structure.
The Foundation Plan shows the location of footings and concrete slabs.
Floor & Roof Structure Layouts
Floor and roof layouts show the outline of the floor truss systems, and slopes, valleys, ridges and hips on the roof.
The wall section is a detailed view showing how the walls are assembled
The electrical plan shows the outlets, switches, lights and fans on the floor plan.
The detail page includes typical construction notes, and specific detailing.
